Tannus Armour
Semi-foam puncture-resistant insert that is placed between the inner tube and the tire of folding bikes, providing complete protection against punctures and side cuts.
Developed with patented Aither technology, it is strong, lightweight, flexible, and incredibly durable (over 7,000 km). It allows for running at very low pressures, thus increasing grip, reducing vibrations, and improving overall performance.
It combines with
Description
Tannus Armour is a Semi-mousse designed to be placed between the inner tube and the tire . The insert protects against punctures from sharp objects, pinch flats from rim damage (snake bites), and sidewall cuts.
The Tannus Armour provides nearly 360° protection from bead to bead , creating an internal protective structure for the tire. This allows driving at much lower pressures without the tire deforming, becoming sluggish, or difficult to control.
It absorbs a significant amount of ground vibrations (for example, areas of loose gravel) and dissipates the energy evenly throughout the chamber. The result is a much smoother, quieter, and more comfortable ride.
It is the first “semi-mousse”, UNIQUE on the market. Developed with the globally patented Aither compound, it has a base of 1,000,000,000 (one billion) micro “bubbles” of sealed air and olefin polymer; representing a major innovation for the cycling world.
Tannus Armour is ideal for the Off-Road & MTB segment.
2-in-1 PROTECTION: ANTI-PUNCTURE and ANTI-RIM SPLASH
The Tannus Armour features a base protection between 13 and 15mm thick, as well as reinforced side protection between 2 and 5mm .
This eliminates 90% of punctures caused by the 4 main threats:
SHARP OBJECTS, SIDE CUTS, BLOWS and PINCHES .
In stock! We ship within 24-48 hours
Personal and friendly service
Tannus Armour
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
-
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
-
FAQs
Use this text to answer questions in as much detail as possible for your customers.
-
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
PUNCTURE PROTECTION
TIRE IMPACT PROTECTION
RIDE-FLAT TECHNOLOGY
VIBRATION ABSORPTION
FIND YOUR ARMOUR
Busca la talla de tu neumático (ETRTO) para saber el Armour compatible con ella.
MTB
20" / 24" / 26" / 27.5" / 29"
Gravel
700C
fat
20" / 24" / 26"
urban
20" / 24" / 26" / 700C
| CUBIERTA | CÁMARA | PESO |
|---|---|---|
| 20" x 1.75-1.90" | 20" x 1.5-1.95" | 190g |
| 20" x 1.95-2.5" | 20" x 1.95-2.1" | 220g |
| 20" x 3.0-4.0" | 20" x 2.4-4.5" | 360g |
| 20" x 4.1-4.8" | 20" x 3.6-4.8" | 370g |
| 24" x 1.95-2.5" | 24" x 1.95-2.1" | 270g |
| 24" x 3.0-4.0" | 24" x 2.4-3.0" | 480g |
| CUBIERTA | CÁMARA | PESO |
|---|---|---|
| 26" x 1.6-1.9" | 26" x 1.1-1.5" | 260g |
| 26" x 1.95-2.5" | 26" x 1.75-2.1" | 300g |
| 26" x 2.6-3.0" | 26" x 1.75-2.4" | 430g |
| 26" x 4.0-4.8" | 26" x 3.8-4.8" | 550g |
| 27.5" x 1.95-2.5" | 27.5" x 1.95-2.1" | 310g |
| 27.5" x 2.6-3.0" | 27.5" x 2.0-2.4" | 330g |
| CUBIERTA | CÁMARA | PESO |
|---|---|---|
| 29" x 1.95-2.5" | 29" x 1.95-2.1" | 320g |
| 29"+ x 2.6-3.0" | 29" x 2.0-2.4" | 350g |
| 700 x 28-34c | 700 x 20-25c | 200g |
| 700 x 35-40c | 700 x 20-28c | 230g |
| 700 x 42-47c | 700 x 28-40c | 290g |
More product details
What is Tannus Armour?
Tannus Armour is the first semi-foam anti-puncture insert on the market to work with inner tubes and protect them from punctures caused by sharp objects, pinches from rim damage (snake bites) and side cuts ( unique on the market ).
Which Tannus Armour model should I choose?
You will need to choose the Tannus Armour that is within the range of your tire and rim.
It is important that both elements are within the compatibility range of Tannus Armour.
It's very simple, we'll tell you how to check it here.
¿Qué cámara de aire debo escoger para mi Tannus Armour?
Tannus Armour occupies some space within the cover initially reserved for the inner tube, which is why you should use a narrower inner tube size than you would normally use.
The size of the air chamber depends on the tire size we use.
In the air chamber range that we indicate for each size, it is important that it is never greater than the maximum range marked.
The recommended inner tube size is always indicated on the packaging and website.
It is important to respect this aspect to guarantee effectiveness against punctures.
We have this camera size suitable, you simply have to select the size of the Tannus Armour you are going to buy and select it from the drop-down menu.
You'll see that you can easily add air chambers by clicking on them.
Is it compatible with ultralight TPU inner tubes (e.g. Eclipse/Tubolito) and tubes with Slime sealant?
Tannus Armour is compatible with TPU (thermoelastomer) (polyurethane) inner tubes. This type of inner tube helps optimize the overall weight of the wheel assembly.
Ultralight inner tubes are expensive compared to traditional butyl tubes, but thanks to the price of Tannus Armour, the combination of the two is in the price range of a tubeless liner. Not bad, right?
We offer an ultralight TPU air chamber (ECLIPSE) compatible with every Tannus Armour. Simply select the size of the Tannus Armour you wish to purchase from the drop-down menu.
Tannus Armour can also be used with inner tubes containing sealant (slime), although it's not necessary. However, if you want to add extra protection, that's fine too.
Even if it can be used, make sure that the size is the correct and recommended size in each case, as indicated on the packaging, assembly guide and website.
What is the active ingredient in Tannus Armour?
Tannus Armour is made from a patented material called Aither. It's a high-quality, foam-like polymer that offers vibration damping, a smoother ride, and puncture resistance.
What benefits does Tannus Armour offer?
Complete Protection : difficult to puncture, protection against punctures, side cuts and pinch flats.
More Comfort : noticeably absorbs vibrations for a smoother ride.
Maximum Control : allows you to ride at low pressures for greater grip and better handling.
Lightweight and Durable : great balance between speed and protection, +7,000km without maintenance.
Can I use the Tannus Armour without a tube?
No. Tannus Armour is designed to work with an inner tube; it cannot be used without one.
For Tubeless protection you should choose the special reference for it: Tannus Tubeless .
¿Es compatible con cámara de aire Tubolito y Slime?
Tannus Armour is compatible with Tubolito inner tubes or similar (thermo-elastomer) (polyurethane). This type of inner tube helps optimize the overall weight of the wheel assembly.
Ultralight inner tubes are expensive compared to traditional butyl tubes, but thanks to the price of Tannus Armour, the combination of the two is in the same price range as a tubeless liner. Not bad, right?
Tannus Armour can also be used with inner tubes containing puncture sealant (slime), but it's not necessary. However, if you want to add extra protection, there's no problem.
Although it can be used, check that the size is appropriate and recommended in each case as indicated on the packaging, assembly guide and website.
¿Qué presión se debe utilizar cuando usas Tannus Armour?
It definitely depends on personal preferences and also on the cycling discipline you practice.
However, the golden rule for MTB:
- For previous Tubeless users, try a pressure 5-6 PSI (0.37 BAR) lower than what you would normally be riding at.
- For air chamber users, try about 10 PSI (0.68 BAR) less.
- For those who have no idea what pressures to use, inflate to a high pressure of about 25 PSI (1.7 BAR) and gradually reduce the pressure until you feel that the pressure is not too low for riding.
- For Gravel and Road bikes, again, it depends on each person's personal preferences, but what we recommend is to start at about ⅔ of the pressure you normally use.
¿Cuándo se debe recortar el Tannus Armour? ¿Afecta al rendimiento?
Tannus Armour should be trimmed according to the size of the tire being used.
If it is not trimmed when indicated or is trimmed when it should not be, it will not be installed properly and therefore will affect performance.
Not all Tannus Armour garments have the cut line, as some sizes do not require trimming.
The instructions are always indicated on the packaging, assembly guide and website.
Always make the cut with scissors.
Are tools needed for assembly?
Tannus Armour is easy to install; these are the only tools required, and they are not always necessary:
- Scissors ( To cut the armor, according to the size of cover used)
- Levers ( To facilitate tire beading )
- Talcum powder ( To facilitate tire seating )
What tips do you recommend for assembly?
Tannus Armour is easy to assemble, however the following tips can make assembly even easier:
Before assembly, you must check that you are using the correct air chamber and following the cutting instructions.
- Thoroughly clean any remaining sealant and foreign objects from inside your tire
- First, place one side of the cover over one side of the rim.
- Use a little talcum powder to make it easier to seat the Tannus Armour on the rim.
- An additional precaution is to ensure that the Armour does not pinch the camera when it is fitted.
- Lightly inflate the inner tube and begin placing it on the tire through the valve.
- Insert the other wing of the Tannus Armour inside the tire; this will facilitate bead seating.
- Finally, seat the other side of the tire on the rim and proceed to the final steps:
Deflate the inner tube and adjust the armor.
Center the Armour around the wheel
Inflate to a high pressure for adjustment
